Structural Sections
Flat Bar & Straps
Rolled flats from 20 × 5 mm to 100 × 10 mm.
Hot-rolled flat bar and straps for fabrication, gates, grilles, brackets and light structural work, produced on the group's own section and strap line. Consistent section tolerance means predictable weight per metre, which is what matters when a fabricator is buying by the tonne.
Sizes
- 20 × 5
- 25 × 5
- 30 × 10
- 40 × 10
- 50 × 10
- 60 × 10
- 80 × 10
- 100 × 10
Standards
- ISO 630-1:2021
- In-house dimensional QC
01Highlights
Predictable weight per metre
Straight, flat and free from twist
Cut to length on order
Widths from 20 mm to 100 mm
02Specifications
- Product form
- Hot-rolled flat bar / strap
- Width
- 20 – 100 mm
- Thickness
- 5 – 10 mm
- Length
- To customer requirement
- Finish
- As-rolled
03Applications
- Gates, grilles and railings
- Brackets and fixings
- Light structural fabrication
- Workshop stock
04Weight per metre
| Dimension (a × b mm) | Weight (kg/m) | Dimension (a × b mm) | Weight (kg/m) |
|---|---|---|---|
| 20 × 5 | 0.785 | 50 × 10 | 3.925 |
| 20 × 10 | 1.570 | 60 × 5 | 2.355 |
| 25 × 5 | 0.980 | 60 × 10 | 4.710 |
| 25 × 10 | 1.962 | 70 × 5 | 2.747 |
| 30 × 5 | 1.178 | 70 × 10 | 5.495 |
| 30 × 10 | 2.355 | 80 × 5 | 3.140 |
| 40 × 5 | 1.570 | 80 × 10 | 6.280 |
| 40 × 10 | 3.140 | 100 × 6 | 4.710 |
| 50 × 5 | 1.962 | 100 × 10 | 7.850 |
05Gallery
Other products
Get in touch
Tell us the tonnage. We will tell you the lead time.
Send your bar schedule, diameters and delivery point. Quotes go out with a copy of the latest mill test certificate for the sizes you need.
